Intercooler Kit Selections
|
Intercooler Thickness |
4.5 in. (112 mm) or
5.0 in. (125 mm) or
6.0 in (150mm)
|
Intercooler End Tank Style |
Fabricated or
Billet
|
Intercooler Finish |
Raw or
Gloss black powder coat or
Matte black powder coat or
Wrinkle black powder coat or
Polished
|
Add Dual Seal Clamp Assembly to Intercooler Hot Side (Welding Cost + DS Assembly) |
Do Not Add or
Add 3.0" dual seal to hot side of intercooler (works with both 3.0 and 2.5 pipes)
|
Add Dual Seal Clamp Assembly to Intercooler Cold Side (Welding Cost + DS Assembly) |
Do Not Add or
Add 3.0" dual seal to cold side of intercooler (works with both 3.0 and 2.5 pipes) or
Add 3.5" dual seal to cold side of intercooler
|
Hot Side Intercooler Pipe Size |
2.5" or
3.0" or
No Hot Side Piping
|
Turbo Manifold Fitment |
2JZ-GTE Street Torque Manifold or
2JZ-GE Street Torque Using Factory Intake Manifold or
2JZ-GE Street Torque Using Font Facing Intake Manifold or
PHR Tubular Style Manifold or
Stock Twin Turbos (Supra) or
Stock Twin Turbos (JZS147 Aristo) or
HKS or
Other (Customer Provided) or
No Hot Side Piping
|
Hot Side Intercooler Pipe Finish |
None or
Gloss Black Powder Coat or
Matte Black Powder Coat or
Wrinkle Black Powder Coat or
Polished
|
Add Dual Seal Clamp Assembly to Compressor Cover (Welding Cost + DS Assembly) (Customer supplied or part of order) |
Do Not Add or
Add 2.5" dual seal to compressor cover or
Add 3.0" dual seal to compressor cover
|
Add Blow Off Valve or Flange to Hot Side Intercooler Piping (welding cost + valve or flange) |
No Blow Off Valve or Flange or
TurboSmart Raceport Black or
TurboSmart Raceport Sleeper or
TurboSmart Raceport Blue or
TurboSmart Raceport Purple or
TurboSmart Raceport Red or
Add Tial Q BOV Black or
Add Turbosmart Race Port BOV Flange Only or
Add Tial Q BOV Flange Only
|
Cold Side Intercooler Pipe Size |
2.5" or
3.0" or
3.5" or
No Cold Side Piping
|
Intake Manifold Fitment |
Stock Non-Turbo (over the valve covers) or
Stock Twin Turbo or
Hypertune or
Plazmaman or
Ebay (McLoytolty, Deepmotor, ProTunerz style) or
Other (Customer Provided) or
No Cold Side Piping
|
Throttle Body Fitment |
Stock Throttle Body or
PHR 74mm Bosch DBW Adapter Kit or
85mm (Cable) or
90mm (Cable) or
Bosch 82mm (DBW) or
Other (Customer Provided) or
97mm (Cable) or
102mm (Cable) or
No Cold Side Piping
|
Cold Side Intercooler Pipe Finish |
None or
Gloss Black Powder Coat or
Matte Black Powder Coat or
Wrinkle Black Powder Coat or
Polished
|
Add Throttle Body Adapter |
Do Not Add or
Add PHR Bosch 82mm Throttle Body Adapter to 3.0" Tubing or
Add PHR Bosch 82mm Throttle Body Adapter to 3.5" Tubing or
Add PHR Bosch 82mm Throttle Body Adapter to 3.0" Dual Seal or
Add PHR Bosch 82mm Throttle Body Adapter to 3.5" Dual Seal
|
Add Dual Seal Clamp Assembly to Throttle Body End (Welding Cost + DS Assembly) |
Do Not Add or
Add 3.0" dual seal clamp to throttle body end of pipe or
Add 3.5" dual seal clamp to throttle body end of pipe
|
Add Blow Off Valve or Flange to Cold Side Intercooler Piping (welding cost + valve or flange) |
No Blow Off Valve or Flange or
TurboSmart Raceport Black or
TurboSmart Raceport Sleeper or
TurboSmart Raceport Blue or
TurboSmart Raceport Purple or
TurboSmart Raceport Red or
Add Tial Q BOV or
Add Turbosmart Race Port BOV Flange Only or
Add Tial BOV Flange Only
|
Add Air Temp (IAT) Sensor Bung to Cold Side (welding cost + sensor cost) |
No Air Temp Sensor Bung or Sensor or
Add AEM Air Temp Sensor or
Add WHP Air Temp Sensor or
Weld 3/8 NPT Bung Only or
Add PRODRAG RealTime IAT Sensor System or
Add T1 Fast Response Air Temp Sensor or
Weld 1/8 NPT Bung Only
|
Add Radiator Overflow Tank |
No Radiator Overflow or
Add Economy Radiator Overflow or
Add PHR Radiator Overflow, Raw or
Add PHR Radiator Overflow, Gloss Black or
Add PHR Radiator Overflow, Matte Black or
Add PHR Radiator Overflow, Wrinkle Black or
Add PHR Radiator Overflow, Polished
|
