Material
Aluminum
Tab Thickness (A)
0.25 in (6.4 mm)
Tab Overal Length (B)
1.45 in (36 mm)
Tab Width (C)
1.0 in (25.4 mm)
Tab Hole or Slot Center to Edge (D)
0.95 in (24.1 mm)
Tab Hole or Slot Width (E)
0.375 in hole
Tab Hole or Slot Height (F)
0.375 in hole
|
Material
Aluminum
Tab Thickness (A)
0.25 in (6.4 mm)
Tab Overal Length (B)
3.125 in (79.4 mm)
Tab Width (C)
1.0 in (25.4 mm)
Tab Hole or Slot Center to Edge (D)
2.437 in (61.9 mm)
Tab Hole or Slot Width (E)
0.375 in. (9.5 mm)
Tab Hole or Slot Height (F)
0.75 in (19 mm)
|
Material
Aluminum
Tab Thickness (A)
0.125 in. (3.2 mm)
Tab Overal Length (B)
2.6 in. (66.0 mm)
Tab Width (C)
0.75 in (19.0 mm)
Tab Hole or Slot Center to Edge (D)
2.035 in. (51.7 mm)
Tab Hole or Slot Width (E)
0.306 in. (7.8 mm)
Tab Hole or Slot Height (F)
0.687 in (17.4 mm)
|
|
Material
Aluminum
Tab Thickness (A)
0.188 in. (4.8 mm)
Tab Overal Length (B)
2.0 in. (50.8 mm)
Tab Width (C)
1.0 in (25.4 mm)
Tab Hole or Slot Center to Edge (D)
1.5 in. (38.1 mm)
Tab Hole or Slot Width (E)
0.375 in. (9.5 mm)
Tab Hole or Slot Height (F)
0.375 in (9.5 mm)
|
Material
Aluminum
Tab Thickness (A)
0.125 in. (3.2 mm)
Tab Overal Length (B)
1.607 in. (40.8 mm)
Tab Width (C)
1.42 in (36.1 mm)
Tab Hole or Slot Center to Edge (D)
1.147 in. (29.1 mm)
Tab Hole or Slot Width (E)
0.545 in. (13.8 mm)
Tab Hole or Slot Height (F)
.295 in (7.5 mm)
|
|
